Uniportal VATS lymphadenectomy

Antonio E. Martin-Ucar1, Laura Socci2

1Thoracic Surgery Units, University Hospitals Coventry and Warwickshire NHS Trust, Coventry, UK, 2Sheffield Teaching Hospitals NHS Trust, Sheffield, UK

Contributions: (I) Conception and design: All authors; (II) Administrative support: All authors; (III) Provision of study materials or patients: All authors; (IV) Collection and assembly of data: All authors; (V) Data analysis and interpretation: All authors; (VI) Manuscript writing: All authors; (VII) Final approval of manuscript: All authors.

Correspondence to: Antonio E. Martin-Ucar. Consultant Thoracic Surgeon, University Hospitals Coventry and Warwickshire NHS Trust, Clifford Bridge Road, Coventry CV2 2DX, UK. Email: antonio.martin-ucar@uhcw.nhs.uk.

Abstract: Lymphadenectomy is an important part of the surgical treatment for lung malignancies. The criticism of limitations in minimally invasive techniques regarding lymphadenectomy has been shown not to be evidenced. We describe the techniques of mediastinal lymphadenectomies during the uniportal VATS (uniVATS) approach with video attachments.

Keywords: Surgical technique; lung cancer; education


Received: 24 August 2017; Accepted: 25 August 2017; Published: 12 September 2017.

doi: 10.21037/vats.2017.08.16


Introduction

Lymphadenectomy is an intrinsic part of surgery for lung cancer. Over the years there have been discrepancies about the possible curative effect of it, but it is clear that improves accurate staging. One of the fears and criticism in the past over the use of minimally invasive approaches has been the possibility to perform a lymphadenectomy without an open incision. These fears and criticisms could potentially be applied again to the further advance of VATS surgery, the uniportal VATS (uniVATS) approach. Authors have demonstrated in recent literature of the equivalency between the uniVATS and the traditional multiport VATS approaches in respect of lymph nodes access and yield (1-4).

Indeed, when accurate and honest audit and report of the extent of lymphadenectomy during pulmonary surgery even with a thoracotomy approach there are shortcomings even in leading oncological units (5-7). There is now extensive evidence in the form of case series and comparison of cohorts that the approach via uniVATS does not carry any limitations per se, and the limits are defined by experience and dedication to lymphadenectomy (8-10).

The traditional uniVATS approach is performed via a limited anterior incision without the use of a rib spreader with an extension that would permit retrieval of the specimen. We recommend to maintain the optics at the most lateral end of the incision trying to occupy as little of the wound as possible that will allow insertion and manipulation of instruments without crowding. With this approach and the optics at the apex of the pleural cavity in the lateral position, all areas of the pleural cavity can be exposed and visualised (11). We describe the techniques of the different nodal stations

Station 8 and 9 (inferior pulmonary ligament and paraoesophageal)

In order to access the lower stations with the uniVATS approach it is recommended to place the optic in the most lateral edge of the incision. It is directed towards the phase of the pleural cavity with the lower lobe retracted cranially to allow exposure of the inferior pulmonary ligament. The optic and the retractor can be hold by the assistant while the surgeon uses bimanual instrumentation to divide the inferior pulmonary ligament. During the initial division of the ligament it is sometimes helpful to push the diaphragm caudally if it is elevated due to the muscle relaxation during anaesthesia and even more in obese patients.

We favour the use of energy devices although electrocautery can be as effective. Once the inferior ligament is divided the posterior mediastinal pleura is divided towards the subcarinal space and stations 8 and 9 are exposed (Figure 1). As with every station, both extensive dissection (lymph nodes and whole fatty perinodal tissue) or an excision directed towards lymph nodes only can be achieved.

Figure 1 Stations 8–9. After division of the inferior pulmonary ligament the posterior mediastinal pleura is divided cranially exposing the regional lymph nodes (12). The use of energy devices or electrocautery minimises blood loss and facilitates the dissection. Available online: http://www.asvide.com/articles/1696

Excision of these stations rarely cause bleeding or complications, although care with surrounding structures is important. These are the oesophagus which can be visualised once posterior mediastinal pleura is divided, the inferior pulmonary vein, and the thoracic aorta which can be damaged accidentally if the electrocautery is not well controlled depth-wise.

Station 7 (subcarinal)

The subcarinal space is, in the opinion of the authors, the one that requires more dedication to explore by surgeons both in open and minimally invasive approaches. It is understandable that following a difficult pulmonary resection the surgeon’s enthusiasm to continue the procedure can be impaired. A way to deal with this could be to perform the lymphadenectomy at the start of the procedure, which can also aid later dissection. The uniVATS approach subcarinal exploration before or after the pulmonary resection.

We do favour tilting the operating table towards the surgeon in order to expose the back of the lung easier. By division of the posterior mediastinal pleura upwards from the inferior pulmonary ligament the subcarinal space is identified below the inferior border of the lower bronchus, between the inferior pulmonary vein and the lower bronchus itself. The optic remains at the most lateral edge of the incision, and the lung is retracted anteriorly either by grasping it or by pressure forwards with a pledget (Figures 2,3).

Figure 2 Station 7. From the left side, the lung is retracted anteriorly and table is rotated towards the surgeon (13). The posterior mediastinal pleura is dissected, and the station 7 is identified between the inferior border of the left main bronchus and the upper border of the inferior pulmonary vein. Available online: http://www.asvide.com/articles/1697
Figure 3 Station 7. On the right side, the posterior mediastinal pleura is divided, and with the lung retracted anteriorly, the subcarinal area is explored below the right main bronchus (14). Energy devices assist haemostasis that can occur from feeding vessels to the lymph nodes or bronchial arteries. Available online: http://www.asvide.com/articles/1698

Bimanual instrumentation with either a lymph node grasper and suction or energy device/electrocautery permits progressive excision of station 7 lymph nodes. This station accessed posteriorly must be explore in depth in order to remove the subcarinal space and not only the lymph nodes below the lower bronchus. If required, the contralateral main bronchus can be visualised via uniVATS.

Exploration of the subcarinal space can frequently cause some bleeding from the lymph nodes or their small feeding vessels, but more importantly from the bronchial arteries that can be damaged during excision. We believe that the use of energy devices helps in maintaining haemostasis during the surgery.

The subcarinal space during uniVATS can also be accessed via an “anterior approach” in the right side between the inferior pulmonary and middle lobe veins, and in the left side between the inferior pulmonary and lingular veins, where the lower lobe bronchus can be found and its inferior border followed towards the station 7 lymph nodes.

Stations 5 and 6 (aortopulmonary window and pre-aortic)

In left sided procedures stations 5 and 6 can be accessed, normally at the initial stages of surgeries for upper lobe as they will help dissection and control of the left main pulmonary artery. The mediastinal pleura proximal to the main pulmonary artery is divided and will expose station 5 lymph nodes (Figure 4). By extending the division of the mediastinal pleura over the aortic arch station 6 is identified. Left hilar station 10 is in close proximity and exposed by extending the dissection of the mediastinal pleura anteriorly towards the hilar structures. The optics remain at the most lateral edge of the wound and the upper lobe is retracted caudally although sometimes raising the head of the operating table suffices.

Figure 4 Station 5. The aortopulmonary window can be explored by dissection of the mediastinal pleura below the aorta (15). Station 5 lymph nodes are then found and excised using bimanual instrumentation. Available online: http://www.asvide.com/articles/1699

Bimanual instrumentation by the surgeon with the use of grasper forceps and blunt (by suction) or sharp (by energy device or electrocautery) dissection permits excision of these stations (Figure 5). In the uniVATS approach these stations as well as the initial branches of the pulmonary artery are very easily identified and dissected as they are placed directly in front of the optic and instruments. It is clearly very important to maintain control of instruments depth-wise to avoid extremely rare injuries to the aortic adventitia or main pulmonary artery.

Figure 5 The optic (5-mm) is placed at the most lateral edge of the wound while the surgeon performs bimanual instrumentation.

We do recommend in left upper lobe resections to continue the division of the posterior mediastinal pleura caudally in order to facilitate dissection and division of structures later on during the lobectomy.

Station 4L (left lower paratracheal)

During left lung resections, the lower paratracheal space is probably the less explored station both in the open or the VATS approach. It is a station placed deep to the aortopulmonary window, the recurrent laryngeal nerve can be at risk, and in some cases the ligamentum arteriosum can difficult exposure.

Once the station 5 is excised, the base of that space can be explored with care not to damage the left recurrent laryngeal nerve. With care, the station 4L can be reached and excised up to the point of visualising the left side of the trachea (Figure 6). We do favour to perform exploration without the use of electrocautery to avoid neural damage. Potential bleeding from this station is virtually always related to small feeding vessels and can be stopped by pressure or with the use of routine haemostatic agents, not requiring cauterization of this area. In cases of prior extensive cervical mediastinal dissections (VAMLA or TEMLA) this area does not require difficult exploration during lung resection.

Figure 6 Station 4L. After excision of station 5 the area below the aortic arch is entered and left paratracheal station can be accessed (16). Care must be taken not to injury the recurrent laryngeal nerve. Available online: http://www.asvide.com/articles/1700

Station 4R and 2R (right lower and upper paratracheal)

The right paratracheal area can be explored via uniVATS either by lifting the azygos vein or by division of the paratracheal mediastinal pleura above the azygos (Figure 7). The chain is continued caudally with station 10 (hilar) behind the azygos vein, so this dissection is normally performed at the same time during surgery. The optic remains at the lateral edge of the wound and the upper lobe is retracted caudally. As in the left side, elevation of the head of the operating table or performing the upper lobectomy prior to the lymphadenectomy can avoid the use of the retractor.

Figure 7 Station 4R and 2R. Exposure of the right paratracheal stations by excising the mediastinal pleura above the azygos vein just lateral to the superior vena cava (17). Bimanual instrumentation and use of energy devices facilitates the lymphadenectomy. Available online: http://www.asvide.com/articles/1701

The lymph node alongside the extensive fat tissue in this area can be excised with bimanual instrumentation between the right side of the trachea and posterior to the superior vena cava (SVC). These stations can bleed due to sizeable feeding vessels and we recommend the use of energy devices with or without further use of local haemostatics. UniVATS exposure allows very proximal exploration of this paratracheal space to the level of higher lymph nodes.

Station 3 (anterior pretracheal)

During right-sided surgeries, the anterior station 3 can be accessed by incising the pleura medially to the SVC, above the level that the right main pulmonary artery crosses behind the SVC.

Once the space is entered, again bimanual instrumentation will permit the dissection and excisions of the lymph nodes (Figure 8). The optic is directed toward the front of the patient and the table can be rotated towards the back of the patient to improve exposure.

Figure 8 Station 3A. On the right side, the mediastinal pleura medially to the superior vena cava is divided, with exploration of the anterior tracheal area above the level of the right main pulmonary artery (18). Available online: http://www.asvide.com/articles/1702

Stations 10L and 10R (hilar)

Dissection of the hilar lymph nodes prior to hilar structures during lobectomy will help without a doubt further progress of the procedure. In the left side involves not only excision of the lymph nodes anterior to the main pulmonary artery and superior vein, but by dividing the posterior mediastinal pleura we can access station 10 lymph nodes posterior to the upper bronchus (Figure 9). Care has to be taken to try to preserve the main vagus nerve, and not to injury the branch of the pulmonary artery to segments 2 and 6. On the right side, this station can extend under the azygos vein and continue cranially into station 4R.

Figure 9 Station 10L. Excision of a posterior hilar lymph node on the left side (19). Important steps are the dissection of the posterior mediastinal pleura and preservation of the main Vagus Nerve. Exploration of this area prior to the lung dissection will facilitate the passage of dissectors and staplers to the proximal branches of the pulmonary artery from the anterior uniVATS incision. Available online: http://www.asvide.com/articles/1703

On this side, we should avoid damage to the upper trunk of the pulmonary artery that lies under the station 10, and the azygos vein itself (Figure 10). Once this station is excised, the access to the upper trunk of pulmonary artery and its plane to the upper bronchus becomes very easy to dissect via uniVATS approach.

Figure 10 Station 10R. Excision of a localised hilar lymph node on the right side (20). The use of an energy device and bimanual instrumentation is shown. Once excised, the upper trunk of the pulmonary artery and the plane with the upper bronchus becomes well exposed. Available online: http://www.asvide.com/articles/1704

Summary

UniVATS provides an excellent access to all mediastinal nodal stations during pulmonary resection. The use of lung retraction in addition to movement of the operating table facilitates the procedures. There are no limitations of the technique, rather surgeons’ philosophy and experience. Reports indicate that with uniVATS the yield of mediastinal lymphadenectomy is at least equal as with traditional multiport VATS and to open techniques.

Starting the procedure performing the lymphadenectomy can ensure a more complete exploration and help with subsequent dissection of the hilar structures.
